Overview
The GoldenStar 8000 Series Air Spray Gun by MGD is a complete commercial-grade pressure feed spray system designed for industrial applicators, cabinet shops, and manufacturing facilities requiring extended spray cycles. By housing the coating material in a remote 2-liter pressure tank, the GoldenStar 8000 Series dramatically reduces gun weight in hand, allowing operators to maneuver into awkward angles and paint large surface areas continuously without stopping to refill a top-mounted cup.
Key Features
- Complete 2L Pressure Tank System: Includes a heavy-duty 2-liter fluid pot equipped with a precision air regulator and pressure gauge for exact fluid delivery control.
- Dual 6-Foot Hose Assembly: Flexible 6-foot fluid and air hose set grants maximum mobility around large workpieces, vehicles, and structures.
- 4 Precision Nozzle Options: Choose from 1.1mm for delicate clearcoats and stains up to 2.0mm for heavy primers, enamels, and high-solid industrial coatings.
- Wide 300mm Pattern Width: Produces a uniform, consistent fan shape for rapid coverage and seamless overlap on broad surfaces.
- Reduced Operator Fatigue: Eliminates the top-heavy weight of standard gravity cups, making long continuous production shifts effortless.
Technical Specifications
- Brand / Series: MGD / GoldenStar 8000 Series
- Technology: Pressure Feed Spray System
- Nozzle Sizes: 0.5mm, 0.8mm, 1.0mm, 1.2mm, 1.4mm
- Working Pressure: 15–28 PSI
- Air Consumption: 280 L/Min
- Fluid Output: 140 c.c./Min
- Pattern Width: 300mm
- Tank Capacity: 2 Liters (with Regulator & Pressure Gauge)
- Hose Length: 6 Feet (Dual Fluid/Air Hoses)
